| Model |
SUN-8K-SG05LP1-EU |
| Battery Input Data |
| Battery Type |
Lead-acid or Lithium-ion |
| Battery Voltage Range (V) |
40~60 |
| Max. Charging Current (A) |
190 |
| Max. Discharging Current (A) |
190 |
| Charging Curve |
3 Stages / Equalization |
| External Temperature Sensor |
Yes |
| Charging Strategy for Li-Ion Battery |
Self-adaption to BMS |
| PV String Input Data |
| Max. DC Input Power (W) |
10400 |
| Rated DC Input Voltage (V) |
370 (125~500) |
| Start-up Voltage (V) |
125 |
| MPPT Range (V) |
150~425 |
| Full Load DC Voltage Range (V) |
200-425 |
| PV Input Current (A) |
26+26 |
| Max. PV ISC (A) |
34+34 |
| No. of MPP Trackers |
2 |
| No. of Strings per MPP Tracker |
2+2 |
| AC Output Data |
| Rated AC Output Active Power (W) |
8000 |
| Max. AC Output Active Power (W) |
8800 |
| AC Output Rated Current (A) |
36.4/34.8 |
| Max. AC Output Current (A) |
40/38.3 |
| Max. Continuous AC Passthrough (A) |
50 |
| Peak Power (off grid) |
2 times of rated power, 10 S |
| Power Factor Adjustment Range |
0.8 leading to 0.8 lagging |
| Rated Input/Output Voltage/Range (V) |
220/230 Vac (Single phase) |
| Rated Input/Output Grid Frequency/Range |
50Hz/60Hz |
| Grid Connection Form |
L/N/PE |
| Total Harmonics Current Distortion (THDi) |
<3% (of nominal power) |
| DC Current Injection |
<0.5% In |
| Efficiency |
| Max. Efficiency |
97.60% |
| Euro Efficiency |
96.50% |
| MPPT Efficiency |
99.90% |
| Protection |
| Integrated |
Anti-islanding Protection, PV String Input Reverse Polarity Protection, Insulation Resistor Detection, Residual Current Monitoring Unit, Output Over Current Protection, Output Shorted Protection, Surge Protection |
| Over Voltage Category |
DC Type II / AC Type Ⅲ |
| Certifications and Standards |
| Grid Regulation |
IEC 61727, IEC 62116, CEI 0-21, EN 50549, NRS 097, RD 140, UNE 217002, OVE-Richtlinie R25, G99, VDE-AR-N 4105 |
| Safety EMC / Standard |
IEC/EN 61000-6-1/2/3/4, IEC/EN 62109-1, IEC/EN 62109-2 |
| General Data |
| Operating Temperature Range (℃) |
-40 to +60℃, >45℃ Derating |
| Cooling |
Smart cooling |
| Noise (dB) |
≤30 dB |
| Communication with BMS |
RS485; CAN |
| Weight (kg) |
20.5 |
| Cabinet Size (W × H × D mm) |
330W × 580H × 232D (Excluding Connectors and Brackets) |
| Protection Degree |
IP65 |
| Installation Style |
Wall-mounted |
| Warranty |
5 Years |
